The ABB ACS580 is a general purpose Variable Frequency Drive (VFD) designed for reliable, energy-efficient motor control across a wide range of industrial applications.
Suitable for pumps, fans, compressors, conveyors, mixers and other process equipment, the ACS580 combines ease of use, robust construction and flexible installation in one scalable drive platform.
For lower-power, cabinet-mounted applications requiring basic speed control, the ABB ACS480 provides a complementary option within the same general purpose family.
Need help sizing your VSD?
Replacing an obsolete drive, upgrading an existing system or planning a new installation, ACS can help specify the right solution for your motor, process and site conditions.
Select your load variables below to instantly compute recommended drive configurations.
Suggested Unit
ACS2000 Series
42% Annual
Why Choose the ACS580?
Multi-application use: Pumps, fans, compressors, conveyors, mixers and general process equipment.
Easy setup: Built-in features and assistant-based commissioning.
Reliable operation: Robust construction, protection features and enclosure options.
Energy efficient: Matches motor speed to real process demand.
Flexible installation: Wall-mounted, drive module and cabinet-built options.
Locally supported by ACS: Specification, supply, build, commission, maintain, Remote Condition Monitoring (RCM) and lifecycle support from ACS Drives.
Easy To Use
User friendly interface in a local language, control
macros and application specific features
Versatile
Wide power range and various construction types, extensive I/O options and support for multiple automation protocols
Easy To Use
Rugged & Robust Protective hardware and software options to make the drive last
Extruders * Cooling & Refrigeration Systems * Industrial Washing & Drying Machines * Agricultural Ventilation Systems * Process Cooling Systems * Auxiliary Motor Control Applications * Compressors * Conveyors * Mixers * Centrifuges * Extruders * General Variable-Torque & Constant-Torque Applications * Pumps & Pumping Systems * Fans & Blowers
Technical Overview
ACS580-01 Wall-Mounted Drives
0.75 kW to 355 kW
230 V and 380–480 V
IP21, IP55 and IP66 depending on frame and option
ACS580-01 Wall-Mounted Drives
0.75 kW to 355 kW
230 V and 380–480 V
IP21, IP55 and IP66 depending on frame and option
ACS580-07 Cabinet-Built Drives
30 kW to 500 kW
380–480 V
IP21 standard; IP42 and IP54 options
ACS480 Compact Companion Drive
0.75 kW to 22 kW
230 V and 380–480 V
IP20
ACS580 + IE5 SynRM Packages
5.5 kW to 315 kW package examples
400 V package examples
Typically IP55; drive protection depends on ACS580 variant
